| EnGenius ECW160 Cloud AC1300 Wi-Fi5 2x2 Outdoor Access Point
EnGenius ECW160 Cloud AC1300 Wi-Fi5 2x2 Outdoor Access Point
เพิ่มเมื่อ: 2019-09-02 16:54:20.0
แก้ไขล่าสุด: 2025-01-07 16:50:48.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comAccess Point (แอคเซสพอยซ์ภายนอก) EnGenius ECW160 Cloud AC1300 Wi-Fi5 2x2 Outdoor Access Point (สินค้ารับประกัน 3 ปี)
EnGenius ECW160
Access Point EnGenius ECW160 Cloud AC1300 Wi-Fi5 2x2 Outdoor Access Point
- Managed by EnGenius Cloud
- 11ac Wave 2 Wireless Speeds to 867Mbps on 5GHz; to 400Mbps on 2.4GHz
- IP67-Rated Weatherproof & Dustproof Housing Withstands Harsh Environments
- Dual-Radio MU-MIMO Improves Performance & Expands User Capacities
- Beamforming Optimizes Antenna Signal, Reception & Reliability for Clients
- Four (4) Detachable 5dbi High-Gain, 360° SMA-Type Antennas
Technical Specifications
Standards
- IEEE 802.11b/g/n on 2.4GHz
- IEEE802.11a/n/ac on 5GHz
Antenna
- 2.4 GHz: Two(2) detachable 5.0dBi SMA antennas
- 5 GHz: Two(2) detachable 5.0dBi SMA antennas
Physical Interface
- 1 x 10/100/1000 Gigabit Ethernet Ports
- 1 x Reset Button
LED Indicators
- 1 x Power
- 1 x LAN
- 1 x 2.4 GHz
- 1 x 5 GHz
Power Source
- Power-over-Ethernet: Proprietary 48V PoE
- IEEE 802.11e Compliant Source
- Active Ethernet (PoE)
Maximum Power Consumption
- 12.6W
Surge Protection
- 1KV
ESD Protection
- Contact: 4KV
- Air: 8 KV
Management Features
Multiple BSSID
- 8 SSIDs on both 2.4GHz and 5GHz bands
VLAN Tagging
- Supports 802.1q SSID-to-VLAN Tagging
- Cross-band VLAN Pass Through
- Management VLAN
QoS (Quality of Service)
Complaint with IEEE 802.11e Standard
Band Steering
- RSSI Threshold
- Traffic Shaping
- Save Configuration as Default
- Auto Transmit Power
- Auto Channel Selection
- Site Survey
- PMK Caching
Control Features
- Distance Control (ACK Timeout)
- Multicast Supported
- Fast Roaming
- Email Alerts
- Wi-Fi Scheduler
- Client Traffic Status
- Guest Network
- RADIUS Accounting
- Power Save Mode (U-APSD Support)
- CLI Support
SNMP
- v1, v2c, v3
MIB
- I/II, Private MIB
Wireless Security
- WEP Encryption 64/128/152 bit
- WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES)
- Hide SSID in Beacons
- MAC Address Filtering, Up to 64 MACs per SSID
- Wireless STA (Client) Connected List
- Https
- SSH
- Client Isolation
Environmental & Physical
Temperature Range
- Operating: -4º~140ºF/-20ºC~60ºC
- Storage: -40Fº~176ºF/-40ºC~80ºC
Humidity (non-condensing)
- Operating: 90% or less
- Storage: 90% or less
Waterproof & Dustproof
- IP67-Rated Enclosure
Dimensions & Weight
ECW160 Device
- Width: 4.36” (111.2 mm)
- Length: 6.83” (173.6 mm)
- Height” 1.19” (30.29 mm)
Package Contents
- 1 – ECW160 Cloud Managed Outdoor Access Point
- 1- Pole-Mounting Strap
- 1 – Wall-Mount Screw Set
- 2 – 2.4GHz 5dBi SMA Antennas
- 2 – 5GHz 5dBi SMA Antennas
- 1 – Quick Installation Guide
Certifications
- FCC
- CE
- IC
